H127 |
|
MATERIAL
Extruded Aluminum, Steel Pin and Ball Bearing |
 |
 |
|
Aluminum, Dark
Bronze Anodized
STANDARD ACCESSORIES
2 1/8'' Shims for flush door application
12 One-way screws
4 Cover Strips
|
|
HEAVY DUTY BEARING HINGES
FOR DOORS WEIGHT UP TO 300LBS(136KGS)
Learn more ... |
|
 |
|
|
|
|
|
|
| |
|
|
|
|
H1130 |
|
 |
|
Extruded aluminum door hinge
60mm fixing c/c distance
Steel pin
Nylon bushing and cap
Loading capacity of 2 hinges:
120kgs, of 3 hinges: 140 kgs |
|
|
|
|
Anodized /
RAL Coating
ACCESSORIES
2 securing aluminum plates with spring
4 relative fixing screws
1 steel safety pin |
|
 |
|
|
|
|
|
|
| |
|
|
|
|
H1131 |
|
|
|
Extruded aluminum door hinge
60mm fixing c/c distance
Steel pin
Nylon bushing and cap
Loading capacity of 2 hinges:
120kgs, of 3 hinges: 140 kgs |
|
|
|
|
Anodized /
RAL Coating
ACCESSORIES
3 securing aluminum plates with spring
6 relative fixing screws
1 steel safety pin |
|
 |
|
|
|
|
|
|
| |
|
|
|
|
H1129 |
|
|
|
Extruded aluminum door hinge
63.5 mm fixing c/c distance
Steel pin
Nylon bushing for adjustment of door
Non-handed |
|
|
|
|
Anodized /
RAL Coating
ACCESSORIES
2 securing aluminum plates with spring
4 relative fixing screws
1 set screw |
|
 |
|
|
|
|
|
|
| |
|
|
|
|
H1127 |
|
|
|
Extruded aluminum door hinge
60mm fixing c/c distance
Steel pin
Nylon washer and offset bushing
for adjustment of door
Loading capacity of 2 hinges:
120kgs, of 3 hinges: 140 kgs |
|
|
|
|
Anodized /
RAL Coating
ACCESSORIES
2 securing aluminum plates
Relative fixing screws
|
|
 |
|
|
|
|
|
|
| |
|
|
|
|
H1128 |
|
|
|
Extruded aluminum door hinge
60mm fixing c/c distance
Steel pin
Nylon washer and offset bushing
for adjustment of door
Loading capacity of 2 hinges:
120kgs, of 3 hinges: 140 kgs |
|
|
|
|
Anodized /
RAL Coating
ACCESSORIES
2 securing aluminum plates
Relative fixing screws
|
|
 |
|
|
|
|
|
|
|
|
